Description
The Panasonic VL2330 is a compact rechargeable coin-type battery from Panasonic’s VL series. It uses vanadium-lithium rechargeable chemistry and provides a nominal voltage of 3V with a nominal capacity of 50mAh.
This version is supplied with pre-attached solder tabs, making it suitable for compatible PCB and equipment installations where a tabbed rechargeable backup battery is required.
| Specification | Details |
|---|---|
| Brand | Panasonic |
| Model | VL2330 |
| Battery type | Rechargeable coin battery |
| Chemistry | Vanadium Lithium |
| Nominal voltage | 3V |
| Nominal capacity | 50mAh |
| Charging voltage | 3.25–3.55V |
| Continuous standard drain | 0.10mA |
| Diameter | 23mm* |
| Height | 3mm* |
| Operating temperature | -20°C to +60°C |
| Terminal | Pre-attached solder tabs |
| Quantity | 1 Piece |
*Cell dimensions are specified without tabs. Panasonic states approximately 3.5g weight without tabs.
